NEC SL1100 SLNet License 1100092
Non-returnable
$236.00
Out of stock
- Provides VoIP networking capability between SL1100 sites
SKU
BE111659 Model
Sl-SYS-SLNET-LIC Warranty
N/A Product Details
Provides VoIP networking capability between SL1100 sites.
Features
- Intercom between all sites
- BLF (Busy lamp fields) across network
- Centralized park slots across network
Usage
With R3.5 system software or higher, the maximum combined network trunk and station ports total is 256. (Earlier software levels provided a maximum of 168.)
Requirements
- Requires SL1100 System Software 1.5 or higher.
- Each system in the network must be equipped with a VoIP Daughter Board (BE110290), which provides (16) VoIP channels.
- To increase the quantity of VoIP channels to the maximum of (32), add (1) 16-Channel VoIP License (BE111131).
- The quantity of VoIP channels (16 or 32) that is required for each SLNet site is determined by the amount of VoIP traffic at that site (IP phones, SIP trunks, and SLNetworking).
- A minimum of (1) SLNet 8-channel license is required for each site in the network.
Max Limit
- Max (5) sites per network.
- Max (32) network channels.
- Max (256) combined total ports across the entire network.
License Scope
System-wide license
