NEC SL2100 SLNet 8-Channel License BE116749

Provides (8) channels of VoIP networking capability between remote SL2100 sites. Additional SLNet 8-Channel Licenses can be added to a site – based on the network traffic requirement.

Features

• Intercom between all sites
• BLF (Busy lamp fields) across network
• Centralized park slots across network

Usage

A minimum of (1) SLNet 8-channel license is required for each site in the network.
Max (51) sites per network.

Each system in the network must be equipped with an appropriate quantity of VoIP channels to handle that system's network traffic.
(8) VoIP channels are built into the SL2100 CPU card and additional VoIP channels can be added with a VoIP Daughterboard.
The quantity of VoIP channels that is required for each SLNet site is determined by the amount of VoIP traffic at that site (IP phones, SIP trunks, and SLNetworking).

Port Usage

Max (256) combined total ports across the entire network.
This includes:

• All equipped digital & analog station ports (used and unused)
• Registered IP telephones, including mobility apps
• Programmed Mobile Extensions
• All equipped PRI/T1 & analog trunk ports (used and unused)
• SIP Trunks
• InMail ports and Virtual Extensions are not included in the total.

Notes

Can also be used to network SL2100 sites with SL1100 sites. However, the maximum number of sites to which an SL1100 system can be networked is (4).

Max Limit

Max (16) SLNet 8-channel licenses per site.
A minimum of (1) SLNet 8-Channel License is required for each site in the network.
Max (51) sites per network.
Max (256) combined total ports across the entire network.

License Scope

8-channel license
